Ikinor 75 Inch Interactive Tablet Touch Smart Board Interactive Whiteboard White Board
Original price was: NPR 292,300.00.NPR 248,455.00Current price is: NPR 248,455.00.
1. All-in-one smart board interactive whiteboard;
2. Applicate for Meeting Room;
3. Updated Android 11 OS, Ram 4G Rom32G, Maximum can be Ram8G Rom64G
4. Feature: Ultra HD 4K Resolution, Fluent Writing Experience, Easy Access Port, Optional Built-in OPS, 20 Watt Speaker.
Description
Product Description
Classroom 75 Inch Interactive Tablet Touch Smart Board Interactive Whiteboard White Board
Avaliable sizes: 75″|86″Available
Key features for IK series Interactive Panel
Customized your interactive board
IKinor Android 11 IFP supports users to personalize the screen, like wallpaper, theme, boot image, language, etc.
Smart Whiteboard
Writing, commenting, erasing, scaning and taking away, the whiteboard APP is easy and convenient to use
All in one interactive display
4 kinds of device can be mirrored on one screen, so the data tables can be clearly compared.
Ikinor Interactive Whiteboard Brief Spec
|
Product Name
|
IR touch Education smart panel
|
Optional size
|
65”,75”,86”,98”,110”.
|
|
|
Android version
|
Android 11
|
Main Chip
|
AMlogic T982
|
|
|
CPU
|
Quad core Arm Cortex-A55
|
RAM,ROM
|
4GB,32GB
|
|
|
Size of product(mm)
|
1706*1022*92
|
Product Type
|
75”.
|
|
|
Size of package(mm)
|
1820*1240*200
|
G.W.(KGS)
|
68KG
|
|
|
Brightness
|
max 400cd/m²(typ.)
|
Life time
|
50000H
|
|
|
Viewing angle
|
178°
|
Contrast ratio
|
5000:1(typ.)
|
|
|
support OS
|
Windows,Android,mac OS,Linux
|
Working temperature
|
0~45ºC
|
|
|
Standard OS
|
Windows
|
CPU
|
i3/i5/i7 optional
|
|
|
Power of speaker
|
8Ω10W*2
|
Built-in camera(optional)
|
1300MP
|
|
|
Android interface(I/O)
|
||||
|
Front ports
|
USB3.0*3,Touch USB1,HDMI in*1.
|
|||
|
Back ports
|
AV IN*1, VGA IN*1, VGA Audio IN*1, HDMI IN*1, Touch USB*1, Android USB 2.0*1,EAPRHONE*1.
|
|||
|
Front buttons
|
Indicator: Red/Blue; Buttons:Screen Record; Image Aspect Ratio; V-; V+; Setting ; Eye Protect; Power
|
|||
|
|||||||||||||
| Model | Spec detail | IK65 | IK75 | IK86 | IK98 | IK110 | |||||||
| Display specification | |||||||||||||
| Diagonal display size | 65″ | 75″ | 86″ | 98″ | 110″ | ||||||||
| Bezel color | Aluminum frame(Silver color) | √ | √ | √ | √ | √ | |||||||
| Back Light | Direct type LED | √ | √ | √ | √ | √ | |||||||
| Active area (mm) | (H) * (V) | 1428.48 * 803.52 | 1649.66 * 927.93 | 1895.04 * 1065.96 | 2158.85 * 1214.35 | 2436.48 * 1370.52 | |||||||
| Resolution | 3840*2160 /UHD | √ | √ | √ | √ | √ | |||||||
| Aspect Ratio | 16:9 | √ | √ | √ | √ | √ | |||||||
| Contrast Ratio | 1200:1/4000:1 | √ | √ | √ | √ | √ | |||||||
| Colors | 1.07 billion colors | √ | √ | √ | √ | √ | |||||||
| Brightness | 350cd/m2 | √ | √ | √ | √ | √ | |||||||
| Viewing angle | 178° | √ | √ | √ | √ | √ | |||||||
| Glass hardness | Mohs-7 level | √ | √ | √ | √ | √ | |||||||
| Screen surface | 4mm thickness Anti-Glare glass | √ | √ | √ | √ | √ | |||||||
| Panel Interactivity | |||||||||||||
| Touch technology | IR touch | √ | √ | √ | √ | √ | |||||||
| Touch points | 20 points (Win 7/8/10) 10 points touch (Android) |
√ | √ | √ | √ | √ | |||||||
| Touch accuracy | ±2mm(Windows) | √ | √ | √ | √ | √ | |||||||
| Recognition | Finger or passive stylus | √ | √ | √ | √ | √ | |||||||
| Response Rate | <4ms(single touch) <10ms(max touch inputs) |
√ | √ | √ | √ | √ | |||||||
| Minimum object size | 2mm | √ | √ | √ | √ | √ | |||||||
| Response Time | <5 ms | √ | √ | √ | √ | √ | |||||||
| System support | Win10/Win8/Win7/Mac OS /Android/Chrome OS/Linux |
√ | √ | √ | √ | √ | |||||||
| Front side Connectivity | |||||||||||||
| Front ports | USB3.0 * 3 lines (Public for both Android & PC) ; Touch out USB A type * 1 line; HD in 2.0 * 1 line; Type C* 1 Line | ||||||||||||
| Front Button | Indicator: Red/Blue; Buttons:Screen Record; Image Aspect Ratio; V-; V+; Setting ; Eye Protect; Power | ||||||||||||
| Front speaker | 15W*2 | ||||||||||||
| Rear side Connectivity | |||||||||||||
| USB 2.0 Type A | 2 | √ | √ | √ | √ | √ | |||||||
| Touch USB 2.0 Type A | 1 | √ | √ | √ | √ | √ | |||||||
| HD in | 2 | √ | √ | √ | √ | √ | |||||||
| RJ45 in & out (public for Android & PC) |
1 | √ | √ | √ | √ | √ | |||||||
| SPDIF OUT | 1 | √ | √ | √ | √ | √ | |||||||
| AV in | 1 | √ | √ | √ | √ | √ | |||||||
| AV out | 1 | √ | √ | √ | √ | √ | |||||||
| VGA in | 1 | √ | √ | √ | √ | √ | |||||||
| VGA audio in | 1 | √ | √ | √ | √ | √ | |||||||
| Earephone | 1 | √ | √ | √ | √ | √ | |||||||
| MIC in | 1 | √ | √ | √ | √ | √ | |||||||
| YPBPR IN | 1 | √ | √ | √ | √ | √ | |||||||
| TF CARD | 1 | √ | √ | √ | √ | √ | |||||||
| RS232 | 1 | √ | √ | √ | √ | √ | |||||||
| Windows OPS Slot | OPS & OPS-C Intel standard | √ | √ | √ | √ | √ | |||||||
| Hotspot | Yes | √ | √ | √ | √ | √ | |||||||
| Bluetooth | V 5.0 | √ | √ | √ | √ | √ | |||||||
| WiFi | IEEE802.11 a/b/g/n Dual Band 2.4GHz/5 GHz Or IEEE802.11an 2.4GHz |
√ | √ | √ | √ | √ | |||||||
| Operating system | |||||||||||||
| Android Version | Android 11.0 | √ | √ | √ | √ | √ | |||||||
| Chipset | Amlogic T982 | √ | √ | √ | √ | √ | |||||||
| CPU | 4×ARM Cortex-A55 | √ | √ | √ | √ | √ | |||||||
| GPU | RM Mali-G52 | √ | √ | √ | √ | √ | |||||||
| RAM | DDR4 2GB (4G for Optional) | √ | √ | √ | √ | √ | |||||||
| ROM | 16GB (32GB for Optional) | √ | √ | √ | √ | √ | |||||||
| Compliant with | Windows; Mac; Linux; Chrome OS | √ | √ | √ | √ | √ | |||||||
| Physical specifications | |||||||||||||
| Net Weight | (kg±2) | 45 | 58 | 80 | 92 | 110 | |||||||
| Gross Weight | (kg±2) | 56 | 68 | 93 | 110 | 144 | |||||||
| Overall size(mm) (without bracket) |
(L*H*W) | 1483.8 * 898 * 91 | 1706 * 1022 * 91.2 | 1958.8* 1154.4 * 91.2 | 2216 * 1314.5 * 95.5 | 2499.6 * 1474.2 * 95.5 | |||||||
| Overall size(mm) (with bracket) |
(L*H*W) | 1483.8 * 898 * 121 | 1706 * 1022 * 121.2 | 1958.8*1154.4*121.2 | 2216 * 1314.5 * 125.5 | 2499.6 * 1474.2 * 137.5 | |||||||
| Carton size(mm) | (L*H*W) | 1590 * 1110 * 200 | 1820 * 1240 * 200 | 2060*1370*200 | 2362 * 1533 * 210 | 2606 * 1593.1 * 200 | |||||||
| VESA | (mm) | 500*400 | 600*400 | 800*400 | 1000*400 | 1200*600 | |||||||
| Electrical | |||||||||||||
| Input Voltage | 90-264V AC | √ | √ | √ | √ | √ | |||||||
| Power Consumption(Standby) | <0.5W | √ | √ | √ | √ | √ | |||||||
| Power Consumption | Maximun< 225W | Maximun< 335W | Maximun< 450W | Maximun< 650W | Maximun< 760W | ||||||||
| Environmental | |||||||||||||
| Working Temperature |
0℃ ~ 40℃ | √ | √ | √ | √ | √ | |||||||
| Storage Temperature |
一20℃ ~ 60℃ | √ | √ | √ | √ | √ | |||||||
| Working Humidity | 10% ~ 90% RH Non-Condensing |
√ | √ | √ | √ | √ | |||||||
| Storage Humidity | 10% ~ 60% RH Non-Condensing |
√ | √ | √ | √ | √ | |||||||
